Self-priming filter pump "CHEMIFINE"
CT
| ・YD-13B5CT1 |
| ・YD-20A6CT1 |
| ・YD-20Y6CT1 |
| ・YD-2000CT1 |
| |
| |
|
|
Features
|
Superior durability
Priming water remaining inside the pump prevents dry running. |
Free layout
Self-priming = More choice of installation site. |
Compact
All-in-one system with filter housing and self-priming pump. |
Easy maintenance
It has a simple structure because of a magnet drive pump. Just loose 8 bolts to exchange filters. |
| It is possible to use the pump for transferring liquid as a chemical pump or filtring liquid as a filter pump. |
|
Examples of Use
|
| For filtering liquid in laboratories |
| For filtering liquid in production lines |
| For self-priming pump to transfer chemical liquid |
|
|
<Small CT> Main material: GFR PP Upper temperature limit: 60℃
| Model |
Bore (mm) |
Limited
S.G. |
Std. performance (m_L/min.) |
Output
(kW) |
Phase |
Weight
(Kg) |
| Suc. |
Dis. |
50Hz |
60Hz |
| YD-13B5CT1 |
13 |
13 |
1.2 |
3 - 7 |
4 - 10 |
0.55 |
1 |
3.9 |
| Capacity of filtration (Clear water) |
Less than 10 L/min. |
| Minimum flow (Clear water) |
2 L/min. |
| Self-priming ability (0.5m) |
35 seconds |
| Limit of self-priming (m) |
2.5 (Clear water at 25℃) |
| Maximum pressure (25℃) |
100kPa |
| Available cartridge filter |
| Depth filter (Marketed product, separately) |
| Filter |
Length |
125 mm |
| Inner bore |
Min. Φ28 mm |
| Outer bore |
Φ65 mm |
<CT> Main material: GFR PP Upper tempaerature limit: 70℃
| Model |
Bore (mm) |
Limited
S.G. |
Std. performance (m_L/min.) |
Output
(kW) |
Phase |
Weight
(Kg) |
| Suc. |
Dis. |
50Hz |
60Hz |
| YD-2000CT1 |
20 |
20 |
1.6 |
6 - 30 |
7 - 30 |
0.4 |
3 |
13.1 |
| YD-20A6CT1 |
20 |
20 |
1.2 |
6 - 30 |
7 - 30 |
0.26 |
1 |
11.6 |
| YD-20Y6CT1 |
3 |
| Capacity of filtration (Clear water) |
600-2400 L/h. |
| Minimum flow (Clear water) |
5 L/min. |
| Self-priming ability (2m) |
50Hz: 90 seconds, 60Hz: 60 seconds |
| Limit of self-priming (m) |
2.5 (Clear water at 25℃) |
| Suitable plating tank |
100 - 800 L |
| Maximum pressure (25℃) |
100kPa |
| Available cartridge filter |
| (Marketed product, separately) |
| Filter |
Length |
250 mm |
| Inner bore |
Φ26 mm and over |
| Outer bore |
Less than Φ125 mm |
